Does anyone have the above info? There seems to be nothing in the owner's manual, and the lid of my fuse box only has its part number on the inside. I'm looking to check the fuse for the rear window demist, which doesn't appear to work. So far, I think the fuse is one of the big ones in the bottom row...
Cheers,
Nick
Fuse box plan for 987 Boxster 2011
Moderator: Moderators
-
nickst4
- Posts: 14
- Joined: Sun Jul 19, 2020 4:32 pm
- TIPEC membership: 9059
-
stratfordshark
- Posts: 1469
- Joined: Mon Nov 05, 2007 11:22 pm
- TIPEC membership: 4635
- Location: Stratford-upon-Avon
Re: Fuse box plan for 987 Boxster 2011
Fuse 9, top row is 25A rear window demist
- Attachments
-
- fuses.jpg (73.67 KiB) Viewed 10234 times
928 S4 Amazon Green 91MY
-
nickst4
- Posts: 14
- Joined: Sun Jul 19, 2020 4:32 pm
- TIPEC membership: 9059
Re: Fuse box plan for 987 Boxster 2011
Hi stratfordshark,
Many thanks for that. Now I must work out how to get a paper copy. Shouldn't be too difficult!
Nick
Many thanks for that. Now I must work out how to get a paper copy. Shouldn't be too difficult!
Nick
-
stratfordshark
- Posts: 1469
- Joined: Mon Nov 05, 2007 11:22 pm
- TIPEC membership: 4635
- Location: Stratford-upon-Avon
Re: Fuse box plan for 987 Boxster 2011
My pleasure Nick. You should be able to download the image, if not I can PM you the file but I just found it online. I'm surprised that same diagram is not in the owner's manual though, or under the panel cover? I'm used to the older Porsches where they took pains to provide that info!
Cheers
Adrian
Cheers
Adrian
928 S4 Amazon Green 91MY
-
nickst4
- Posts: 14
- Joined: Sun Jul 19, 2020 4:32 pm
- TIPEC membership: 9059
Re: Fuse box plan for 987 Boxster 2011
Hi Adrian,
OK, the Missus managed to generate a paper version of the plan and I checked the relevant fuse and it was fine. That suggests I was wrong in thinking the demister wasn't working, or the connection to it via the folding hood is poor or broken. Not really a big deal, and it's good to have got the fuse plan.
Cheers,
Nick
OK, the Missus managed to generate a paper version of the plan and I checked the relevant fuse and it was fine. That suggests I was wrong in thinking the demister wasn't working, or the connection to it via the folding hood is poor or broken. Not really a big deal, and it's good to have got the fuse plan.
Cheers,
Nick
